A4FO Hydraulic Pump
c sw cvsd
v svsef
v wsvse
csdcsw

A4FO Replacement Axial Piston Fixed Pump

Features：
▶ Fixed pump in axial piston swashplate design for hydrostatic drives in an open circuit
▶ For use in mobile and stationary applications
▶ Flow is proportional to the drive speed and displacement.
▶ High power density
▶ High total efficiency
▶ Optimized dimensions for special installation situations
▶ Excellent suction characteristics
▶ Low noise level
▶ Long service life
▶ Economical design
▶ Through drive for combining additional pumps
▶ Sizes 22 and 28
– Nominal pressure 400 bar
– Maximum pressure 450 bar
▶ Sizes 71 to 500
– Nominal pressure 350 bar
– Maximum pressure 400 bar

Size 22 28 71 125 180 250 500 250 500
Series Standard High-speed
Displacement (per rotary group) Vg max cm³ 22 28 71 125 180 250 500 250 500
Nominal pressure pnom bar
Maximum pressure pmax bar 400 400 350 350 350 350 350 350 350
Maximum speed 1) at Vg max nnom rpm 450 450 400 400 450 400 400 400 400
Flow pump 1 at Vg max and nnom qV nom1 l/min 3600 3000 2200 1800 1800 1500 1320 1900 1500
Flow pump 2 at Vg max and nnom qV nom2 l/min 79 84 156 225 324 375 660 475 750
Power at qV nom and pnom P kW 53 56 91 131 189 219 385 277 438
Torque at Vg max and pnom M Nm 140 178 396 696 1003 1393 2785 1393 2785
Weight (approx.)   m kg 13.5 13.5 34 61 76 120 220 120 220
  Machine Hydraulci Pump/Motor
Construction Machinery
Concrete mixer AA2FM A4VTG EATON 5423
Concrete transport pump A2FO A4VG A11V
Wet spraying machine A11V A2FM A10V
Road roller A6VE A6VM  A4VTG P2VC
Paver A6VE A6VM  P2VC P4VC
Grader A6VM  P2VC
Asphalt spreader P1V(A)O A2FM
Milling machine P1V(A)O A2FE A2FM
Crawler excavator P3VO
Wheel excavator A6V A6VM  P3VO
Loader M3VE A6VM  P2VC A10VSO A2FM
Bulldozer A6VM  P2VC
Material Handling Machinery
Crane A2FE A6V A6VM P2VC P1V(A)O A10VSO A2FM
Forklift
Drilling Rig A2FE A6VE A6VM P1V(A)O A10VSO A2FM
Heading Machine A2FE P1V(A)O
Mining Truck A10VSO
Agricultural Machinery
Tractor A6VE P2VC P4VC A10VSO
 Rice Transplanter
Combine Harvester A6VE A4VTG P2VC
Pesticide machine A6VE A4VTG P2VC A10VSO
Rice harvester A6VE A4VTG P2VC P4VC
Sugar Cane Harvester A6VE P2VC P4VC A10VSO A2FM
Municipal Machinery
Airport Equipment A6VM P2VC P1V(A)C A10VSO A2FE A2FM
Firfighting Truck A7VO P1V(A)C A10VSO
Snow Sweeper P2VC A10VSO
Aerial work platform P4VC A10VSO
Electric Power A2FE A6VE P2VC P4VC
Environmental Sanitation Vehicle
Anti Dust Vehicle
Oil And Gas Equipment
Liquid Nitrogen Pump Truck P1V(A)O
Fracturing Truck A6VM P2VC A2FO A2FM
Fracturing Blender Truck A6VM P2VC A10VSO A2FM
Coil Tubing A10VSO A2FE
Pipelayer A2FE A6VM P1V(A)O
Industrial Application
Injection molding machine
Shoe-making machine A10VSO
Metal forming machinery A7V
CNC machine tool PV A10VSO
Metallurgy and die-casting E-A4VG
Flow Machine
Reach Stacker P3VO
Heavy Forlift A6VM A4VTG A10VSO
Tire Crane A6VM
Maritime Port
Ship A6VE A6VM P1V(A)O A10VSO A2FE A2FM
Offshore platform A6VE A6VM P1V(A)O A10VSO A2FE A2FM
Wind power P1V(A)O
Dredging vessels P1V(A)O
Others
Marine Crane A 11VLO A2FM FMF  A4VG A6VM
